The Cranbrook Series - BLC
Suspended Circular
Architectural Lighting
Our architectural lighting products are built for projects where a premium appearance is just as important as performance. With a focus on clean design, quality construction, and flexible customization, they're well suited for offices, commercial buildings, lobbies, and hospitality environments.
BLC - The Cranbrook Series
The BLC is a suspended circular luminaire that has been designed for indoor use, where energy efficiency and performance are essential. Designed and manufactured in Ontario, Canada, this fixture is an elegant solution ideally suited for architectural applications.
| Supported Voltage | 120-277V, 277-480V, 480V |
| Available Sizes | 18" and 24" |
| Lumen Output | Lumen output ranging from 2.5L (2500lm) to 12L (12000lm) |
| Lifetime | L70 of 100,000+ hours |
| CCT | 2700K, 3000K, 3500K, 4000K, 5000K, 6500K |
| CRI | 80+ standard, 90+ and 95+ available |
| Dimming | 0-10V Standard |
| Mounting | Holes provided for aircraft cable and optional pendant mounting |
| Applications | Retail Stores, Professional Sports Facilities, Offices, Hotels, Suspended |
BLSDH - The Hearst Series
The Hearst Series (BLSDH) is an architectural linear lighting solution designed for easy linking with customizable corner and transition elements. Engineered to deliver seamless transitions with no visible light leakage, it offers multiple optic options and continuous runs up to 80 ft. Ideal for offices, aisles, conference rooms, retail spaces, and other architectural environments.
| Supported Voltage | 120-277V, 347V, 120-347V |
| Available Sizes | Linear by 6" increments up to 10', 2x2/4x4 corners, custom pieces available* |
| Lumen Output | Lumen output ranging from 0.25L(250lm) to 2.25L(2250lm) |
| Lifetime | L70 of 99,000+ hours, L90 of 30,000+ hours |
| CCT | 2700K, 3000K, 3500K, 4000K, 5000K, 6500K |
| CRI | 80+ standard, 90+ and 95+ available |
| Dimming | 0-10V Standard |
| Mounting | Holes provided for surface and suspended mounting; Knock-outs for row-mounting |
| Applications | Aisle Lighting, Displays, Grocery Stores, Hospitals, Offices, Retail Stores, Schools, Task Lighting, Suspended, Surface Mount |
BLRD - The Dryden Series
The Dryden Series (BLRD) is a series of architectural recessed fixtures for T-Bar ceiling systems, providing commercial recessed ceiling lighting with a clean, refined appearance for offices, hospitals, grocery stores, manufacturing facilities, and schools.
| Supported Voltage | 120-277V, 120-347V, 347V |
| Available Sizes | 1x4', 2x2', 2x4' |
| Lumen Output | Lumen output ranging from 1x4 / 2x2 to 2x4 |
| Lifetime | L70 of 90,000+ hours |
| CCT | 2700K, 3000K, 3500K, 4000K, 5000K, 6500K |
| CRI | 80+ standard, 90+ and 95+ available |
| Dimming | 0-10V Standard |
| Mounting | Holes provided for chain or hanger, and wire mounting support for T-Bar ceilings |
| Room-Side Serviceability | Standard on all models |
| Applications | Grocery Stores, Hospitals, Manufacturing Facilities, Offices, Retail Stores, Schools, Storage Facilities, Recessed, Surface Mount |
