BLCS
LED Curved Strip
Files and Resources
Description
The BLCS LED curved strip offers a clean, professional look for spaces where efficient task lighting is required. This solution offers UN3(120-347V) voltage, color-selectable CCT and wattage options. The fixture has a hinge-open design for toolless maintenance.
Specifications
| Supported Voltage | 120-347VAC |
| Available Sizes | 4' (47.51"x2.6"x2.7") |
| Lumens | 3250lm(25w), 4500lm(35w), 5800lm(45w) |
| Operating Temperature | -20°/+40°C |
| CCT | 3500K, 4000K, 5000K (selectable) |
| CRI | 80 CRI |
| Dimming | 0-10V Standard |
| Mounting | suspended or surface-mount |
| Sensor | supports 12V AUX |
| Power Factor | >0.9 |
| Applications | Manufacturing Facilities, Storage, Offices, Schools, Retail Stores, Distribution Facilities, Processing Plants, Aisle Lighting |
